Minutes of ASC OP Meeting
Sunday, January 22, 2006, 8:30 a.m. 10:00 a.m.
Fairmont Hotel, Cupertino Room
170 South Market Street, San Jose, CA 95113
Present
Participants (10/18)
Representing
Committee Members
David Aikens
Zygo Corporation
Sam Bailey
Davidson Optronics, Inc.
Gordon Boultbee
JDS Uniphase Corporation
Andrei Brunfeld
Xyratex
Bryan Clark
Xyratex
Walter Czajkowski
APOMA (Edmund Optics)
Frank Dombrowski
Gage-Line Technology, Inc.
Lincoln Endelman
SPIE (Endelman Enterprises)
Charles Gaugh
Davidson Optronics, Inc.
Thomas Germer
NIST
John Hamilton
Northrop Grumman
Rudolf Hartmann
Retired
Hal Johnson
Harold Johnson Optical
John Knaur
Olympus America
Kathleen Richardson
School of Materials Science & Eng., Clemson
William E. Royall (by Phone) Eastman Kodak Company
Trey Turner
Research Electro-Optics, Inc.
Steven VanKerkhove
Corning Tropel
Observers (1)
Gene Kohlenberg
OEOSC
Welcome and Introductions
D. Aikens opened the meeting at 8:37 a.m. Since there were new participants, a round of introductions was completed.
Adoption of Agenda
H. Johnson moved that the draft agenda be adopted. W. Czajkowski seconded the motion, which carried unanimously.
Approval of August 1, 2005, 2005ASC OP Meeting Draft Minutes
M. Dowell moved that the draft minutes be approved. J. Hamilton seconded the motion; the motion passed unanimously.
Reports
Performance Based Optical Surface Imperfection Standard
D. Aikens reported that the group made good progress. The standard will give the notation tool for specification and leave how to
determine the performance relationship up to the engineer. L. Endelman was assigned the task of completing the scope. G. Boultbee's
draft document covering letter notation will be folded into the 4th section of OP1.002.
J. Hamilton recommended that both chrome and iron oxide artifacts be prepared.
Wavefront Specification Project
the task force decided that there is no current US standard that is equivalent to ISO 10110-5 and 14. The task force will first make
a US equivalent, and then will look at a document that looks at techniques so that an operator can perform tests that are consistent from
company to company.
A list of new persons who will be invited was prepared.
Future of ASME 14.18 Optical Drawing Standard
W. Royall said that ASME completely discontinued the standard. The current version needs to updated. There is quite a bit of
interest in the standard. D. Aikens suggested that a copy of the document should be made available to S. VanKerkhove. W. Royall
has a paper copy which could be scanned. J. Hamilton said that he also has a paper copy. D. Aikens asked W. Royall to get a copy to
10/2/2006 12:22:07 PM
Draft Minutes of ASC OP 1-22-06 Meeting.odt
ANSI/OP Draft Minutes continued, Sunday, January 22, 2006, 8:30 a.m. 10:00 a.m.
Fairmont Hotel, Cupertino Room, 170 South Market Street, San Jose, CA 95113
S. VanKerkhove. The secretary volunteered to contact ASME stating that OP would like to assume responsibility for it, and ask if we
could have an electronic version of it. If ASME wants to charge OEOSC, then the secretary would report back to the committee.
D. Aikens proposed that an update to the ASME document be added to the agenda of the October or January meetings.
The ASME 14.5 standard is the de facto international drafting standard. W. Royall said that ASME washed their hands with the
document because H. Pollicove didn't exert energy on the task, and no one else was identified to work on it.
Revision of Scratch and Dig Course
G. Boultbee is the keeper of the master copy of the PP presentation. D. Aikens suggested that the master be kept on a protected
folder on the web site. G. Boultbee reported that several slides have been added to the presentation. He added instructor notes to
make sure that all presenters would follow the philosophy.
Aikens said that the new ISO standard quiz was well received. A lot of interest was generated at Zygo.
G. Boultbee had two presentations at JDSU with more than 90 in attendance. There was a wide range of background experience. He
has been asked to go to JDSU Ottawa and teach another class. He also found that there was interest in how the ISO standard works.
D. Aikens showed micrographs of the Edmund paddle. Scratch width measurement will not work. J. Hamilton said that he got
similar results. SEM images required carbon coating which may change the contour.
G. Boultbee will send the master copy to the secretary to be placed in a protected area of the web site.
L. Endelman said that he tells the exhibitors at conferences about the course. He would like to see a brochure that he could hand
out or that SPIE could distribute to the distributors.
D. Aikens said that when the wavefront standard nears completion, a course should be created, as well as a course for ASME
Y14.18. He thinks that we should also consider creating
ISO Documents that are candidates for adoptions as US standards
The secretary reported that the list of ISO/TC 172/SC 1 and SC 3 standards to be considered for US adoption had been placed on
the OEOSC web site. G. Boultbee had suggested that the series of coating standards should be considered, so copies of those
standards were also placed on the web site under password protection. The ANSI "Guide for Adoption of ISO Standards as ANSI
Standards" and the "ANSI Policy Regarding Rights to Nationally Adopt IEC and ISO Standards or Otherwise Use IEC and ISO
Material" were also placed on the web site. The secretary continued by saying that G. Boultbee proposed the the ISO 9211 documents
be adopted verbatim.
L. Endelman asked what advantage there is for adopting ISO standards as US standards. G. Kohlenberg replied that R. Parks had
proposed that OP adopt ISO standards so that they could become part of our revenue stream. It would be little effort on our part. D.
Aikens asked why someone would by our version rather than the international one. G. Kohlenberg presumed that the US version
would be listed first on the ANSI web site. D. Aikens asked if there would be any leverage with the US military to make these US
standards. J. Hamilton suggested that the decision would be driven by the contracting office. Aikens said that the TAG participants
know which international standards are true collaborations and which ones were driven by one country. However, the operator in an
optics shop would not have any such clear understanding.
D. Aikens asked if the US military industrial complex would prefer US over ISO standards. J. Hamilton said that the contracting
officer determines what specifications are used. In general, they prefer US standards. D. Aikens asked how would a military
procurement officer or engineer know which international standards were actually being followed by the US military/industrial
complex. J. Hamilton said that his experience is that the US military always specifies a US standard first. US standards usually have
default specifications, which the ISO standards do not. So there is a definite advantage for making them US standards.
D. Aikens recommended that OP flag the good ones and adopt them. ISO 9211 is a good standard and should be generally used. L.
Endelman pointed out that if we adopt them we can then modify them more easily if necessary.
W. Royall stated that it would be preferable to have a standard with only one number so that a company would not have to stock
both versions. D. Aikens replied that OP should set a policy that if we are adopting an ISO standard without modification, they should
be designated as ANSI/ISO, and if we are going to change some of the content, then we would issue a new number.
The documents that were of interest are listed as follows:
ISO 517:1996 Photography Apertures and related properties pertaining to photographic lenses Designations and
measurements
ISO 8478:1996 Photography Camera lenses Measurement of ISO spectral transmittance
ISO 9211-1:1994 Optics and optical instruments Optical coatings Part 1: Definitions
ISO 9211-2:1994 Optics and optical instruments Optical coatings Part 2: Optical properties
ISO 9211-3:1994 Optics and optical instruments Optical coatings Part 3: Environmental durability (It has a table for
environmental tests for coatings and references the ISO 9022 series of standards.)
ISO 9039:1994 Optics and optical instruments Quality evaluation of optical systems Determination of distortion
10/2/2006 12:29:39 PM
2
Draft Minutes of ASC OP 1-22-06 Meeting.odt
ANSI/OP Draft Minutes continued, Sunday, January 22, 2006, 8:30 a.m. 10:00 a.m.
Fairmont Hotel, Cupertino Room, 170 South Market Street, San Jose, CA 95113
ISO 14997:2003 Optics and optical instruments Test methods for surface imperfections of optical elements (the task
force may want to think about it.)
D. Aikens suggested that the ISO 9211 series of standards should be balloted for US adoption. He also asked if they could be
grouped as one. He also suggested that OP ballot the MTF specs.
W. Royall said that there is an advantage of having an ANSI/ISO standard because if a contract requires a company to us an ISO
standard, then a company doesn't have to have two copies.
Other Business
There was no other business.
Time and Place for Next OP Meeting
M. Dowell moved that the OP Meetings be held in San Jose, CA during Photonics West annually. H. Johnson seconded the
motion, which carried.
Adjourn
Since there was no further business to come before the committee, J. Hamilton moved that the meeting be adjourned. M. Dowell
seconded the motion. The meeting was adjourned at 10:04 a.m.
