Draft
Minutes
ASC OP1 ASC OP/TF 2, Performance Based Optical Imperfections Task Force Draft Standard Meeting
Sunday August 26, 2007, 8:30 a.m. -- 12 Noon
Present Attendees (13 of 17 Entities)
Committee Members
Representing
David Aikens
Zygo Corporation
Gordon Boultbee
JDSU Corporation
Andrei Brunfeld
Xyrtex
Benjamin Catching (Alternate)
JDSU Corporation
Walter Czajkowski
APOMA (Edmund Optics)
Frank Dombrowski (by phone)
Gage-Line Technology, Inc.
Marla Dowell
IEEE/LEOS (NIST)
Lincoln Endelman
SPIE, (Endelman Enterprises)
Charles Gaugh
Davidson Optronics, Inc.
John Hamilton (by phone)
Northrop Grumman
Hal Johnson (by phone)
Harold Johnson Optical Lab
Rudolf Hartman
Retired
Alan Krisiloff
Triptar Lens Co., Inc.
Jonathan McGuire (Alternate)
Northrop Grumman Laser Systems
Michael Morrill
Lockheed Martin Space Systems Company
Bruce Netherton
Lockheed Martin Coherent Technologies
Sam Richman (Alternate)
Research Electro-Optics, Inc.
William Royall (by phone)
Eastman Kodak Company, Retired
Trey Turner
Research Electro-Optics, Inc.
Steve VanKerkhove
Corning Tropel
Ray Williamson
Ray Williamson Consulting
Observers (1)
Gene Kohlenberg
OEOSC
Auditor's Summary of Meeting
Two representatives from Northrop Grumman presented the results from their examination of the optical surface
imperfection readings recorded by a group of optical inspectors. The conclusion is that the current qualitative test is less
accurate than the optics industry assumes. There was considerable discussion concerning how the conclusion affects the
surface imperfection evaluation that has been traditionally used to grade optical components.
New laser and micro-optics components require the elimination of surface scratches and digs that traditionally were
acceptable for consumer and military products. The current test does not include reference samples small enough to
accommodate these new products. There was concern that the revision of this standard would be delayed significantly if it
were not released until a decision concerning micro-optics and laser components could be completed. The current draft will
be finished at the next meeting so that it can be balloted and then the Task Force will turn to the micro-optics issue.
Eastman Kodak Company had marketed a molded imperfection reference for evaluation of optical surfaces. The
business was sold and the new vendor uses a different method for producing the reference. There was voiced concern that
the new reference did not yield as repeatable results as was formerly obtained using the Kodak product, and yet the product
is sold under the same product number. The companies selling the reference were urged to change the part number so that
optics manufactures would not assume that it is the same product.
The task force agree to meet again in San Jose, CA on January 20, 2008.
1 Welcome and Introductions
G. Boultbee opened the meeting at 9:00 a.m. Since there were several new persons attending the meeting, each one
was introduced.
01/04/08 03:29:34 PM
1 of 6
ASC OP1 Draft Minutes Imperfection, 8-26-07.odt
Check Box
ASC OP1 ASC OP/TF 2, BSR/OEOSC-OP1.002, Optics and Electro-Optical Instruments Optical Elements and
Assemblies -- Appearance Imperfections Task Force Draft Standard Review, Continued
2 Adoption of Agenda
G. Boultbee noticed that C. Gaugh was not present to discuss his item. D. Aikens asked if the status of the Scratch and
Dig paddle could be discussed. G. Boultbee asked for a motion to approve the published agenda with addition of the item
concerning Scratch and Dig Paddle. A. Krisiloff made the motion and M. Dowell provided the second. The motion carried
unanimously.
3 Approval of the Monday, May 14, 2007 ASC OP/SC 1, BSR/OEOSC-OP1.002, Optics and Electro-Optical
unanimously. Instruments Optical Elements and Assemblies -- Appearance Imperfections Draft Review
Minutes
The minutes had been posted on the web site. The Task Force Leader asked if there were any additions or corrections
to the minutes. G. Boultbee offered two changes to the minutes. The first was in section 4, where the word "approve" was
changed to "improve." The second change was in section 5: the sentence was changed to say, "G. Boultbee called for a
break at 10:30 a.m. and then he suggested that the task force address the run of the mill dimensional inspection, then if there
is time, return to T. Turner's method." J. Hamilton moved that the minutes be approved and M. Dowell seconded the
motion. The motion carried unanimously.
4 Scratch and Dig Round Robin
C. Gaugh was not available for this discussion. He had offered to supply artifacts that NIST could use to develop a
round robin test.
5 Northrop Grumman Laser Systems Gage R&R
J. Hamilton stated that the accuracy of imperfection evaluation has become more difficult as optical requirements
become more stringent. Optical components for precision systems are becoming much more expensive, and disagreements
concerning surface imperfections are more critical because of potential expensive scrap losses. Even though the military
imperfection specifications stipulate that they are for appearance purposes only, in practice the specifications are treated as
if the imperfections are measured values. Northrop Grumman has had suppliers' engineers spend as much as a week with
the company trying to correlate what a "60" scratch is on a manufactured component. J. Hamilton said that this is the
continuation of a fifty-year debate which is quantified by the various revisions to the military artifact drawings over the
years.
Northrop Grumman decided to conduct an in-house study of the problem by treating the inspection methodology as an
attribute gage study rather than an optical problem. The earlier NIST study by Mat Young treated the evaluation technique
as an optical problem. Lionel Baker's work also came from an optical perspective.
Because there was no obvious source of visual evaluation discrepancies by a group of students who were being trained
to inspect optical components, Northrop Grumman looked at these inspectors' eye sight, skill level, and experience. They
evaluated the inspection environment and examined the military's and Kodak's reference samples. They then ordered
certified sets of reference samples from Brysen, cut them in half, and used one half as the test sample. This ensured that
"apples" were being compared to "apples." A similar test was designed for Kodak paddles to evaluate those reference
samples. All three inspection environments described in MIL-O-13830 were set up. (The incandescent and fluorescent
inspection environments produce almost the same results.) The Brysen references were evaluated outside of the cases that
the military encloses them in to see if repeatability could be improved.
The intent of the evaluation was to determine how often a failure was missed and how often an acceptable part was
failed. They wanted to determine the reason for reading errors. For the test five trained optical inspectors and five optical
technicians not trained for inspection were selected so that the skill level question could be answered. The eye-sight of each
inspector was tested. Testing done by J. Hamilton's group covered a larger inspector population than the testing done by J.
McGuire's group.
At this point J. McGuire continued the presentation. His testing had to be piggy-backed on other projects. That
minimized the amount of time that could be devoted to the evaluation. He said that the data he was showing at this
meeting, and the data that J. Hamilton would be presenting later show the need for improvement in the inspection system.
J. McGuire used six inspectors three from the receiving inspection department and three quality engineers from the
production floor. All six have been making these types of inspections for a number of years. J. McGuire used the same
Brysen samples that J. Hamilton had prepared. Samples were labeled A, B, C... so that the inspectors had no idea which
scratch number each sample represented. There were ten samples, two each of 10, 20, 40 ,60, and 80. Two samples had a
mirror coating. J. McGuire performed an SCM analysis to confirm that the samples were not compromised when they were
cut in half. Where as J. Hamilton used both military references and Kodak paddles as the comparators, J. McGuire used a
01/04/08 03:29:34 PM
2 of 6
ASC OP1 Draft Minutes Imperfection, 8-26-07.odt
ASC OP1 ASC OP/TF 2, BSR/OEOSC-OP1.002, Optics and Electro-Optical Instruments Optical Elements and
Assemblies -- Appearance Imperfections Task Force Draft Standard Review, Continued
new and old set of military references (encased in a wooden box). There were 240 test data points, half with the new
reference and half with the old reference.
The small sample size leads to large confidence intervals. In order to minimize errors caused by the viewing system,
the same black box with curtains, 40 watt light with opal glass and black matte bars was used. There were a few lint
particles inside the reference cases, but nothing that would compromise the test. The test was explained to the inspectors so
that the unusual event would not confuse them. The test samples were cleaned using standard techniques. J. Hamilton said
that the same cleaning procedure was followed for his test. J. McGuire said that each inspector evaluated each test sample
four times: twice with the old references and twice with the new references. R. Williamson suggested that for any future
testing that the samples be relabeled between multiple readings. J. McGuire said that he did the test himself, and could not
remember what numbers he had assigned to each sample when he did a repeat evaluation. The test procedures used by both
Northrop Grumman divisions presented the samples to each inspector in a random fashion so that there would not be a
tenancy for the inspector to remember the evaluations.
J. McGuire presented charts of the test results showing how each inspector agreed with him or herself as well as
agreement with the reference standard. The inspectors had a higher level of agreement with their own results than they did
with the reference samples. The data was presented as the percentage agreement, i.e., if an inspector chose the same scratch
number three out of five times, then his score was 60%. Bars encompassing the plotted reading illustrated the 95%
confidence interval. A. Krisiloff suggested that the four readings of a sample could be plotted on a graph with each reading
occupying a spot on the x-axis while the four readings would be plotted on the y-axis. Then the standard deviation of those
four readings could be computed to see if there is a tighter correlation.
J. Hamilton said that his data also indicate that inspectors are more consistent with their own readings than they are
with the actual reading.
R. Williamson asked if there was a good correlation of a individual inspector across the two samples that had the same
scratch number. J. Hamilton said that that relationship has not yet been evaluated.
J. McGuire said that the agreement among the inspectors was only 10%. Inspector agreement with the "correct"
reading was 32%. 55% of the time the inspectors report the scratch to be larger than the accepted value. 13% of the time a
smaller reading is reported. A number 10 scratch was always marked as larger than a 10. This was important to J. McGuire
because a large portion of his laser optics have a specification of 10. Practically speaking, either an optical element was
either perfect or it had a scratch that was larger than 10; there were no 10s. On a few occasions inspectors actually read 20s
as if they were 10s.
The inspectors were told that the samples came from reference sets, so the inspectors knew that there were no samples
greater than 80. Therefore, there were no rejections for 80s. A. Krisiloff observed that the data seemed to show that small
scratches are over estimated and large scratches are underestimated. D. Aikens countered that the 40 sample is fairly
accurately identified. There seems to be a psychological bias towards rejection. Since the test samples and the references
came from the same pieces, there should be no bias. M. Dowell asked if a 40 scratch is the most frequently encountered
imperfection so that the inspectors would be more familiar with that size scratch. J. McGuire said that in his organization
the optical components are either very high quality or fairly loose, so examples on both ends of the spectrum should be
more frequently encountered.
D. Aikens observed that the 10 sample was evaluated as high as 80; the 20 was consistently identified as a 40; the 40
was consistently identified as a 40; the 60 almost always was identified as an 80. The samples were no longer in a case,
while the references were still in their case. Were the references harder to see?
J. Hamilton said that he saw the same type of distribution for his test using a larger number of inspectors. In order to
answer the question about visibility of the references in the cases, he bought new references without the cases, and got
essentially the same results.
A. Krisiloff surmised that the results show that the test is working as designed, because if there is doubt the inspector is
instructed to choose the next higher number. In order to confirm this 5, 15, e.t.c, scratches should be created to test if the
binning is working properly. The boundary conditions are being tested rather than the center of the bin. R. Williamson said
that if the protocol said, "which scratch does the sample most closely match," then one would get a very different result.
J. Hamilton said that they modeled the illumination conditions and scratch geometry in Z-Max. When the scratch is
evaluated using Z-Max the same problem occurs. The problem comes from the mono-width variable depth geometry for all
of the scratches in the current military specification for the reference samples. When the range of scratches are evaluated
by Z-Max the different scratch numbers can not be recognized. D. Aikens reported that the reference samples that Brysen
sells are not unit-width, variable depth. The unit-width, variable-depth artifacts are limit samples that are used by Brysen in
the manufacturing process. J. Hamilton countered that when he does electron microscope evaluation of the references, he
finds that they are 7 10 in width.
D. Aikens said that when he does optical evaluations of reference samples, he sees considerable variation in the widths,
although a 10 and a 20 are close to the same width. The 40, 60 and 80 are dramatically different in width.
01/04/08 03:29:34 PM
3 of 6
ASC OP1 Draft Minutes Imperfection, 8-26-07.odt
ASC OP1 ASC OP/TF 2, BSR/OEOSC-OP1.002, Optics and Electro-Optical Instruments Optical Elements and
Assemblies -- Appearance Imperfections Task Force Draft Standard Review, Continued
J. McGuire said that he did similar testing on the samples in his possession, and found that the widths were in the 5
10 range with depths approximately 1 . When measured he determined that a 10 was less than a 60, but a 60 was wider
than an 80. He could not say that there was a correlation between the scratch width and its apparent visibility. D. Aikens
said that theoretically there did not have to be a correlation because the samples are binned by their visibility, not their
physical characteristics.
A. Krisiloff asked if the inspectors could have observed a glint at the edge where the Brysen sample was cut to come to
the conclusion that a 10 appears to be an 80. J. Hamilton said that the inspectors were instructed to ignore the test samples
near the cut edge. J. McGuire did not remember if he gave the same instruction. Since results from the two Northrop
Grumman facilities were similar, J. McGuire assumed that this was not an issue.
A. Krisiloff then asked J. Hamilton and J. McGuire how they explain the situation where 10s were observed as 80s. J.
Hamilton attributed the observations to the fact that the widths of the 10s and 80s were similar, and the human eye cannot
distinguish them as the SIRA instrument can.
D. Aikens made an observation about the data recorded for the older military references. The results for a 10 sample
were noticeably different when the older military references were used. A 10 was never identified as a 10, five times it was
reported as a 20, six times it was identified as a 40, six to eight times it was thought to be a 60, and only once called an 80.
M. Dowell surmised that the reference that is used frequently may have some damage that the older military reference that
sits on the shelf does not exhibit. The old standard would possibly provide a more accurate result. A. Krisiloff suggested
that the profiles of the two sets of references might actually be different. J. Hamilton said that the military had difficulty
making the original reference samples, and the profiles of the scratches is not known. D. Aikens reminded the group that
Brysen reported at a previous meeting that the process for scribing the scratches has not been changed in 40 years. The
scratches are made with differing pressure and then the resulting samples are visually sorted and binned.
G. Boultbee suggested that the samples should be given to Ari Siletz of CCDMETRIX so that they could be evaluated
on the new CCDMETRIX instrument.
J. Hamilton reminded the group that the military only allows vendors to use the current edition of reference samples.
He was able to keep the old set by agreeing to not use them in production.
D. Aikens asked J. Hamilton if the data generated using the Kodak paddle showed the same bias for rejection. J.
Hamilton did not have the data in front of him, but he thought that the Kodak paddle results were marginally better. D.
Aikens said that this observation would support M. Dowell's hypothesis that inspectors are more careful when using a less
familiar reference to grade samples. They have to look at the reference more frequently.
J. Hamilton interjected that this system does not work as a gage device. J. McGuire reinforced that statement by stating
that the old reference results were correct only one-third of the time.
A. Krisiloff said that the sample data looked as if there was the expected bias toward rejection since, in general,
samples were binned one number larger than the actual reading. He asked J. Hamilton how that observation is wrong. J.
Hamilton replied that for $10,000 optics, a company cannot afford an evaluation system that has a 55% chance of rejecting
good product. A. Krisiloff said that the qualitative evaluation, which has large error bars for observations, should be
revised to compensate for the error on the high side. Instead of presenting a 20 reference to the inspector, an 18 should be
the reference. J. McGuire said that there is variability in the Brysen reference samples, so that a 20 reference may be an 18.
A. Krisiloff said that that fact indicts the qualitative test even more. J. Hamilton replied that the problem with the current
test is that it does not take into consideration the tolerance of the reference sample, and it does not account for the
variability introduced by the inspector.
D. Aikens observed that if one has an expensive optical component, then the current qualitative standard should not be
used. The specification should be for scratch widths, and the part should be evaluated under a microscope. J. Hamilton
said that in practice his group uses the Kodak paddle as the first sorting test. He can then distinguish the questionable
samples from the good ones. The scratch width would be measured for the questionable samples.
D. Aikens observed that there is a need for a quick visual check; however, this system is even questionable for fast,
inexpensive testing. A. Krisiloff observed that the current system is valid except for the 10 case. J. McGuire countered that
if all of the observations that were one bin high were removed from the sample population, there were still 31 data samples
that were incorrect. 25% of the time the observation is more than one bin above the correct value. D. Aikens added that
this is a large error bar for commercial transactions. A. Krisiloff said that skipping to a second higher bin is unacceptable.
M. Dowell countered that this result is only true for the new artifact standard; it is not true for the older artifact standard. D.
Aikens said that the 10 specification is meaningless because it is often observed as higher values. G. Boultbee said that this
discussion was mirroring the discussions at earlier meetings where the laser and micro-optic applications were determined
to not be adequately represented by this standard.
G. Boultbee closed the discussion by saying that he was hearing two groups of comments. There were questions for
J. McGuire concerning data that he had not presented, and there were questions concerning what should be done next with
01/04/08 03:29:34 PM
4 of 6
ASC OP1 Draft Minutes Imperfection, 8-26-07.odt
ASC OP1 ASC OP/TF 2, BSR/OEOSC-OP1.002, Optics and Electro-Optical Instruments Optical Elements and
Assemblies -- Appearance Imperfections Task Force Draft Standard Review, Continued
regard to additional studies of the test methodology, and consideration of the acceptability of this standard. He proposed
that the Task Force document the questions that it has
for J. McGuire about other ways to look at his data, and
concerning future studies to resolve issues with the standard.
J. McGuire said that J. Hamilton was planning a report that documented the tests and test results. D. Aikens said that
he would like to see the data that J. McGuire presented released to the optics community. J. Hamilton said that his
organization planned an in-house symposium for November that would include this topic. He said that he always presumed
that the results would be reported in a peer-reviewed publication such as one of the SPIE journals.
J. McGuire said that under the current system vendors double the charge of their components because they expect the
customer to reject half of the components supplied to them.
L. Endelman said that if the methodology and test equipment are not changed, then no amount of additional evaluation
of the test system will change the end result. Everyone agreed.
G. Boultbee said that the Task Force needs to anticipate the questions that may be asked the next time the subject is
presented. J. McGuire said that he would like to extended the testing to include 0s and imperfections in excess of 80, and
do the evaluation in a more blind fashion. J. Hamilton's testing did address issues such as cased reference artifacts vs.
uncased artifacts and the Kodak paddle vs. Brysen reference artifacts. Those who are experienced with surface imperfection
testing new that the current method is qualitative and flawed, but these tests indicate that it is more flawed than previously
assumed.
D. Aikens asked if the Task Force was prepared for him to include the results of this report in the upcoming Scratch
and Dig class in Boston? J. McGuire said that Northrop Grumman considers what he presented at this meeting is now part
of the public domain. M. Dowell said that the students in the class are a different audience than those who are on this Task
Force. The students are looking for answers and this report creates more questions. D. Aikens agreed to not use the data in
the class. G. Boultbee said that D. Aikens could caution the students to be aware of number 10 scratch evaluations. J.
Hamilton urged D. Aikens to wait until after the Northrop Grumman report is published (in the November time frame)
because he could better describe the problem.
J. McGuire said that the testing scope could be expanded to include more operators, operators from different
companies, 0 samples, samples in excess of 80 to expand the imperfection range.
B. Netherton said that he has seen similar testing results for the past 27 years, and would prefer that Northrop
Grumman and Lockheed Martin would work together to conceptualize alternatives to the current test procedure. D. Aikens
added that the ISO 10110 method should be checked to see if it has similar attributes as the current military method or if it
is more robust. He also noted that this Task Force has spent considerable time expanding the current standard to include
physical measurement methods; do they work? Perhaps effort should be directed toward the measurement method to see if
it is more reliable.
L. Endelman summarized the discussion by saying that the current qualitative testing system is better than nothing, but
the optics community does not know how much better than nothing.
At this point G. Boultbee proposed a 10 minute break.
6 Review of Revised OP1.002
G. Boultbee reviewed the status of the draft document by stating that the agreed upon changes to clause 3.7 and Annex
B were incorporated in the 8/26/07 version. Annex C still had to be addressed. The Task Force also must address T.
Turner's RES proposal. G. Boultbee proposed that the draft of the standard with the incorporation of Annex C can be used
for traditional, conventionally-sized optics. What T. Turner proposes for laser/micro-optics applications would be better
served by a new standard dealing directly with imperfections that are on the order of 10-5 and tighter surface quality. The
current draft would be delayed excessively if the effort to incorporate the 10-5 venue were undertaken.
M. Dowell suggested that a notification of the limitation concerning laser and micro-optics be added to the foreword of
the current document. From a laser standpoint, she would prefer to see the 10-5 regime added to a future version of the
current standard because it is all about the qualification of optics. The T. Turner proposal would need to have a similar
evaluation as Northrop Grumman has done for the current visual system before it were to be incorporated into the standard.
G. Boultbee suggested that the Task Force deal with the wording in Annex C, and then go back to the scope to address
any constraints.
D. Aikens said that the Task Force has not addressed functional performance for laser optics. B. Netherton said that in
practice he specifies the use of a laser to inspect. He also uses a scatter test, which has no standard. A. Krisiloff said that it
sounds as if there should be a scatter standard. D. Aikens said that the Task Force is not in the position to address scatter.
M. Dowell asked about an integrating sphere method of measuring scatter for laser rods.
D. Aikens asked if there is a need for a width specification. J. McGuire said that a measured width standard would be
of use.
01/04/08 03:29:34 PM
5 of 6
ASC OP1 Draft Minutes Imperfection, 8-26-07.odt
ASC OP1 ASC OP/TF 2, BSR/OEOSC-OP1.002, Optics and Electro-Optical Instruments Optical Elements and
Assemblies -- Appearance Imperfections Task Force Draft Standard Review, Continued
D. Aikens said that if the Task Force is going to open up the lower end of the artifact range, then there could be letters
"AA" (2 µ), "AAA" (1 µ). M. Dowell countered that a statement specifying the actual number to be called out. To address
this concept, D. Aikens suggested that an "A" followed by a size could be incorporated; an "A2" is a 2 µ scratch. J.
McGuire countered that the letter should be "W", for width, to remove confusion. G. Boultbee said that at some point, say
less than 5µ, microscope viewing is required so that imperfections can be seen.
Because the meeting time limit was approaching, G. Boultbee agreed to draft a proposal for specifying imperfections
that are smaller than the existing range. The Task Force will look at the Foreword, which needs to be updated. D. Aikens
suggested that we give a notation and caution the user about viable measurement in this regime. R. Williamson said he
preferred retaining the Foreword of the first addition and adding a second edition Foreword for the new version. D. Aikens
volunteered to write the text of the Foreword for the second edition down to the paragraph that starts, "Suggestions for
improvement of this standard are welcome." He will give the wording to the Secretary who will incorporate it into the
document.
R. Williamson identified a typographical error in clause 3.1.6, which should read 0.05 0.25.
7 Scratch and Dig Paddle Status
W. Royall said that the original Kodak paddle is out of production. The new Edmund paddles have curved scratches.
He did not have time to evaluate them. D. Aikens has looked at new the paddles, and he did not see as good a correlation
between the old and new. They are manufactured using an entirely different technology than Kodak used. Edmund and
Thor labs sell the paddles under the same part number that was formerly used for the Kodak paddle. D. Aikens urged that
the part numbers be changed. W. Czajkowski said that he would look into this issue at Edmund. D. Aikens will also
investigate.
W. Czajkowski suggested that ultimately reference samples would best be created by replication rather than scribing.
8 Time and Place of next TF 2 Meeting
The Task Force agreed to meet next in San Jose,CA, January 20, 2008, 8:30 a.m. noon.
9 Adjourn
W. Czajkowski moved that the meeting be adjourned; M. Dowell seconded the motion, which carried unanimously.
The meeting adjourned at 12:20 p.m.
01/04/08 03:29:34 PM
6 of 6
ASC OP1 Draft Minutes Imperfection, 8-26-07.odt
